06M121486E Coolant Pipe
This is a catalog item (special order). Delivery time may vary.
Special order item. Delivery time may vary.
About This Part
Available for Purchase
This part is available to order directly from the manufacturer. While it's not currently in our warehouse, we can source it for you and have it shipped to your location.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 1–6 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 1–6 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
6 vehiclesCoolant Pipe — locate Coolant Pipe in the official exploded view and explore the surrounding assembly.
Parts in this assembly38
- 2Hose 4M0122101DR
- 2Hose 4M0122101DN
- 4Pipe 4M0121081CN
- 5Pipe 4M0121081F
- 8Hose 4M0122055CR
- 10Hose 4M0819342AF
- 10Hose 4M0819675P
- 13Water Pipe 06M121661H
- 13Water Pipe 06M121661J
- 13Water Pipe 06M121661D
- 14Bolt N10156206
- 16Water Pipe 06M121486F
- 16Water Pipe 06M121486D
- 17Bolt N91096701
- 18Water Pipe 06M121662D
- 21Grommet 4M0819345B
- 23Hose 4N0121056AJ
- 24Valve 4H0121671G
- 25Element 4N0129669B
- 26Bolt N90731503
- 26Bolt N10666702
- 27Collar Nut N01508210
- 28Bracket 4N0121305F
- 29Bolt N10124309
- 30Hose 4M0122447D
- 31Bracket 4M0121313BP
- 32Screw N10619001
- 34Hose 4M0122449AC
- 35Water Pipe 4M0121485BQ
- 36Ut"hex Nut Self-locking With Washer Hex Nut N90570803
- 37Hose 4M0121449BK
- 40Clamp 06B145917A
- 41Clamp N90686902
- 42Clamp N90687001
- 43Clamp N90926501
- 55Seal 06M121488A
- 55Seal 06M121488
- 56Seal Ring N90097001
Vehicle fitment table6
Europe (5)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Audi Q8 Quattro 3,0 | 2018- | 16 | 1 |
| audi a6 2.0 | 2018- | 44, 19 | 1 |
| Audi A7 Sportback | 2018- | 44, 19 | 1 |
| Audi A8L | 2017-2022 | 48 | 1 |
| Audi Q7 qu. 3.0 TDI | 2015-2019 | 16 | 1 |
Other markets (1)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Audi A7 | 2021- | 44 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Coolant Pipe is fitted on: Audi Q8 Quattro 3,0 2018-; audi a6 2.0 2018-; Audi A7 Sportback 2018-; Audi A8L 2017-2022; Audi Q7 qu. 3.0 TDI 2015-2019; Audi A7 2021-.
