076131512E Radiator
This is a catalog item (special order). Delivery time may vary.
Special order item. Delivery time may vary.
About This Part
Available for Purchase
This part is available to order directly from the manufacturer. While it's not currently in our warehouse, we can source it for you and have it shipped to your location.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 1–6 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 1–6 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
1 vehicleRadiator — locate Radiator in the official exploded view and explore the surrounding assembly.
Parts in this assembly21
- 1Valve 076131501B
- 2Seal Ring WHT002224
- 3Thr Flap 076128063A
- 4Seal Ring WHT002223
- 5Radiator 076131512F
- 6Pipe 076131525D
- 7Seal 069131547D
- 8Bolt N10155906
- 9Screw N91099101
- 10Screw N10405702
- 11Bracket 076131564E
- 12Screw N10347003
- 13Screw N90986102
- 15Bracket 076131184F
- 18Bracket 076131184G
- 19Screw N10682501
- 19Screw N90888502
- 20Collar Nut N10609202
- 21Pipe 076131525C
- 22Ut Hexagon Nut Self-locking Hexagon Nut N90894601
- 23Seal 038131547A
Vehicle fitment table1
Europe (1)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| CRAFTER 06> | 2006- | 5 | 1 | D |
Diagrams & fitment data powered by oemdiagrams.com
Radiator is fitted on: CRAFTER 06> 2006-.
