5F0117340 Air Guide
This is a catalog item (special order). Delivery time may vary.
Special order item. Delivery time may vary.
About This Part
Available for Purchase
This part is available to order directly from the manufacturer. While it's not currently in our warehouse, we can source it for you and have it shipped to your location.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 1–6 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 1–6 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
1 vehicleAir Guide — locate Air Guide in the official exploded view and explore the surrounding assembly.
RThis part is the Right side
Parts in this assembly42
- 1Hose 5Q0122051AF
- 1Hose 5Q0122051B
- 2Coupl Piece 5Q0122291BG
- 2Coupl Piece 7M3122291
- 3Seal Ring N90765301
- 4Spring 1J0121142
- 5Coupl Piece 5Q0122291DS
- 5Coupl Piece 5Q0122291T
- 6Sender 06A919501A
- 7Seal Ring N90316801
- 8Spring 032121142
- 9Grille 5Q0121557A
- 10Hose 5Q0122058Q
- 11Coupl Piece 5Q0122291AB
- 12Water Pipe 5Q0121070BR
- 13Screw N10473402
- 13Screw N10721401
- 14Hose 5Q0121058AE
- 15Hose 5Q0122109J
- 16Hose 5Q0121447G
- 17Bolt WHT003361
- 18Pump 5Q0965561B
- 19Bracket 5Q0121093D
- 20Hose 5Q0121101N
- 21Hose 5Q0121051K
- 22Part 5Q0121251HA
- 22Radiator 5Q0121253H
- 24BracketRight5Q0121093FA
- 24BracketRight5Q0121093FD
- 24Bracket 5Q0121093DG
- 25Rubber Bush 4D0317867A
- 26Water Pipe 5Q0121070BP
- 27Bracket 5Q0121093BD
- 28Washer N90225901
- 29Bolt N10471802
- 31Air GuideRight5F0121674
- 32Air GuideRight5F0117340A
- 33Bracket 5Q0121093T
- 60Clamp N90686701
- 61Clamp N90686902
- 62Clamp N90687001
- 63Clamp N90687101
Vehicle fitment table1
Europe (1)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Leon ST Stylance | 2012-2016 | 32 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Air Guide is fitted on: Leon ST Stylance 2012-2016.
